MT89M 2D Scan Engine
Why Value-Optimized Scan Engines Matter
Cost-conscious devices still need dependable, responsive barcode capture. A value-optimized 2D scan engine delivers fast decoding, low power draw, and compact mechanics so manufacturers can build slim, affordable products without sacrificing performance. This balance lowers BOM cost, simplifies integration, and improves user experience across high-volume deployments in retail, logistics, healthcare, and transit.
How Slim Design + Advanced Algorithms Deliver Performance
A one-piece, low-profile form factor combined with an efficient decoding algorithm provides snappy, accurate reads across 1D and 2D barcodes while keeping power consumption minimal. Electrical and mechanical compatibility with popular engines enables easy drop-in replacement or OEM upgrades, speeding time-to-market for handhelds, kiosks, and embedded terminals that require reliable scanning in tight spaces.
- Slim one-piece, low-profile design
- Cost-effective for high-volume OEM integration
- Low power consumption for longer battery life
- Drop-in electrical/mechanical compatibility
- Fast, responsive decoding across distances
View: https://scankit.istaging.com/TT-20221201-001/TT-20221201-001.html
-
Retail -
Logistics -
Healthcare -
Mobile POS -
Public Transport
FEATURES
Electric and Mechanical Compatibility
MT89M scan engine has a low profile form factor at the size of W21.7 x L10 x H7.2 mm and weight of only 1.4 grams, the 2D Scan Engine can be integrated into most space-constrained products. With mechanical dimensions, screw holes position, electric interface, and pin assignment highly compatible with existing 2D scan engines of global leaders, the MT89M scan engine reduces the development time and cost needed during integration.
Excellent Performance from Near to Far
With auto-adaptive snappy scanning performance, MT89M 2D scan engine provide outstanding performance for portable devices in logistics and warehouse applications where barcodes can be scanned from near to far. Built with high-quality optics and sensors, MT89M scan engine can read high-density barcodes up to 3mil and capture commodity barcodes from 350mm away. MT89M also supports all major 2D barcodes including MaxiCode and Dotcode.
Mobile-Friendly Scanning
Scan Engines MT89M, with enhanced optical design and the latest decode algorithm, virtually scans all 1D and 2D barcodes on any surface, either paper-based label or mobile phone display. With MT89M 2D scan engine integrated into the mobile device, users may expand their business into many new applications such as eCoupon, eTicket, Digital ID cards, and mobile payments.
Easy and Flexible Operations
A set of commands is supported to enable the host device to configure all the functions of MT89M scan engine thereby fulfilling dynamic configurations demand. With multiple interfaces (USB HID, USB VCP, UART) available, the scan engines MT89M fulfills diverse industrial needs of communication methods as well as enables users to easily configure the reading modes and scanner settings according to preference.
SPECIFICATIONS
Visible Red LED
10mil/ 0.25mm (2D)
Vertical 28°
13 Mil UPC/EAN: 46 ~ 238 mm
15 Mil Code128: 44 ~ 291 mm
15 Mil QR Code: 32 ~ 199 mm
6.67 Mil PDF417: 32 ~ 123 mm
10 Mil Data Matrix: 31 ~ 123 mm
USB HID
USB VCP
UPC-A/ UPC-E0/ UPC-E1, EAN-8/ EAN-13, Code128, Code39, Code93, Codabar, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Standard 2 of 5, China Post 25, Code11, MSI Plessey, Plessey, GS1 Databar, GS1 Databar Limited, GS1 Databar Expanded
2D Symbologies:
QR Code, Micro QR Code, PDF417, MicroPDF417, Data Matrix, Aztec, MaxiCode, Han Xin, Code16K
(it requires housing that is designed for ESD protection and stray from electric fields.)
(P/N: 9017-2700000, QTY: 1)
(P/N: 4200-1603110, QTY: 2)
