Marson Barcode Scanner Brand Story

MT8225 2D Handheld Scanner

  • MT8225_2D_Handheld_Scanner
  • MT8225_2D_Handheld_Scanner_cable
  • MT8225_Scan_QRcode
  • MT8225_2D_Handheld_Scanner_Healthcare
  • MT8225_2D_Handheld_Scanner_water
  • MT8225_2D_Handheld_Scanner_Retailshop
  • MT8225_2D_Handheld_Scanner
  • MT8225_2D_Handheld_Scanner_cable
  • MT8225_Scan_QRcode
  • MT8225_2D_Handheld_Scanner_Healthcare
  • MT8225_2D_Handheld_Scanner_water
  • MT8225_2D_Handheld_Scanner_Retailshop

Ergonomic and Durable
MT8225 is a 2D handheld scanner constructed in an ergonomic, pocket-sized form factor and industrial-class protection. Capable of decoding all major 1D and 2D barcodes, this durable, user-friendly handheld scanner is an ideal choice for a variety of applications, including retail, mobile payment, manufacturing, and healthcare.



。2D / Long Range / Tethered / Medical
。Ergonomic and lightweight
。Medical-grade anti-microbial housing
。IP55 dust and water resistance

Application
  • Retail
    Retail
  • Healthcare
    Healthcare
  • Mobile POS
    Mobile POS
  • Manufacturing
    Manufacturing
Share:

FEATURES

Fast 1D & 2D Barcode Data Capture
MT8225, on an average of 1/10 seconds, scans all linear barcodes and major 2D barcodes printed on labels with either matte or glossy surface, or displayed on mobile phone or LCD screen. MT8225 2D handheld barcode scanner also delivers superior scanning in any orientation, which benefits enterprise with less downtime and increased productivity.


Anti-Microbial Scanner for Healthcare
Built with anti-microbial technology, MT8225 can endure repeated alcohol or bleach cleaning and keeps preventing the reproduction and spread of bacteria among nurses in hospital. The disinfectant-ready MT8225 portable scanner enables caregivers to quickly identify patients and dispense medications, keep up-to-date record and manage medical supplies inventory in an error-free manner.


Mobile-Friendly Scanning
With enhanced optical design and latest decode algorithm, MT8225 virtually scans all 1D and 2D barcodes printed on any surface, either paper-based label with either matte or glossy surface, or mobile phone display and LCD screen. As a result users may expand their business into many new applications such as eCoupon, eTicket, Digital ID cards and mobile payments.


Industrial-class Protection
The ruggedized design of MT8225 2D handheld scanner includes industrial-class protection with IP55 sealing and 1.5 meters drop resistance ensuring that MT8225 prevents the infiltration of dust and water spray and withstands the impact of everyday drops and bumps in all kinds of working environments where users are constantly on the move.


The Better User Experience
As classified by Photo-biological Safety Standard EN/IEC 62471, the light source of MT8225 is completely safe for human eyes even after long hours of operation. With built-in buzzer, LED and vibrator, MT8225 2D handheld scanner provide full variety of Good Read responses such as audible, visual, and haptic feedback. MT8225 is also easily configured on the host computer by Marson's free user-friendly software tool, Ez Utility®.

SPECIFICATIONS

Optic & Performance
Light Source
White LED
Visible red LED
Sensor
640 x 480
Resolution
3 Mil / 0.075 mm
Scan Angle
Horizontal 40°
Vertical 30°
Pitch Angle
±60°
Skew Angle
±50°
Roll Angle
360°
Print Contrast Ratio
20%
Width of Field
141mm (13Mil Code39)
Typical D.O.F (Environment: 800 lux)
3 Mil Code 39: 62 ~ 113 mm
5 Mil Code 39: 34 ~ 173 mm
13 Mil UPC/EAN: 52 ~ 403 mm
15 Mil QR Code: 37 ~ 235 mm
6.67 Mil PDF417: 37 ~ 161 mm
10Mil Data Matrix: 37 ~ 156 mm
Physical Characteristics
Dimension
W42.5 x L102 x H21.5 mm
Weight
89 g
Color
Black / White
Material
PC
Connector
USB Type A
Cable
1M Fixed Cable
Trigger
Scan Button, Function Button
Indicator
LED, Buzzer, Vibrator
Electrical
Operation Voltage
5.0 VDC ± 5%
Working Current
< 300mA
Standby Current
< 70mA
Connectivity
Interface/Profile
USB HID
USB VCP
User Environment
Operating Temperature
-20 ~ 50˚C
Storage Temperature
-20 ~ 60˚C
Humidity
0% ~ 95%RH (Non-condensing)
Drop Durability
1.5M
Sealing
IP55
Ambient Light
70,000 Lux (Sunlight)
Decode Capability
Symbologies
1D Symbologies: UPC-A/ UPC-E, EAN-8/ EAN-13, Code128, GS1-128, Code 39, Code32, Code 93, Code11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Codabar, MSI, GS1 Databar

2D Symbologies: QR Code, Micro QR Code, Data Matrix, PDF417, MicroPDF417, Aztec, MaxiCode
Regulatory
ESD
Functional after 4KV contact, 8KV air discharge
Environmental
WEEE, RoHS 2.0
Medical Compliance
ISO 22196 (JIS Z 2801), ISO 11737-1/2
