Marson Barcode Scanner Brand Story

MT8221 2D Handheld Scanner

  • MT8221_Scanner
  • MT8221_Handheld_Scanner_Scanning_Solution
  • MT8221_2D_Handheld_Scanner_04
  • MT8221_2D_Handheld_Scanner_02
  • MT8221_2D_Handheld_Scanner_03
  • MT8221_Scanner
  • MT8221_Handheld_Scanner_Scanning_Solution
  • MT8221_2D_Handheld_Scanner_04
  • MT8221_2D_Handheld_Scanner_02
  • MT8221_2D_Handheld_Scanner_03

Affordable and efficient barcode scanning

MT8221 2D Handheld Scanner Handheld Scanner is an affordable and efficient barcode scanning device designed to meet the needs of various industries, including retail, manufacturing, and mobile payments.



  • 2D / Middle Range / IP54
  • Mobile-friendly scanning from screens
  • Durable IP54-rated, drop-resistant design
  • Ergonomic and economical
Application
  • Retail
    Retail
  • Logistics
    Logistics
  • Manufacturing
    Manufacturing
Share:

FEATURES

Versatile and Reliable Scanning Solution
MT8221 is designed for retail and commercial applications,  Its robust construction ensures durability, easily captures  barcodes on both paper and digital screens of 2D barcodes. This barcode scanner is light in weight and ergonomically designed, offering users a comfortable grip all shift long.This scanner delivers superior performance in a wide range of environments, from direct sunlight to complete darkness.



Superior Barcode Data Capture
MT8221 2D Handheld Scanner excels in barcode data capture, decoding all major 1D and 2D symbologies such as GS1 Composite, MaxiCode, Aztec, and more. With a scanning speed of approximately 1/10 of a second, it ensures quick and accurate barcode reading from any orientation. This superior performance contributes to increased productivity and reduced downtime, making it a valuable asset for enterprises.



Environmental Interference Immunity
Designed for both indoor and outdoor use, the MT8221 is equipped with immunity to ambient light interference. It automatically adjusts its parameters to maintain optimal scanning performance, even in challenging lighting conditions such as direct sunlight or complete darkness. This adaptability provides users with the freedom to scan barcodes in various environments without compromising accuracy.



Mobile-Friendly Scanning
Thanks to its advanced optical design and state-of-the-art decode algorithm, the MT8221 can read barcodes from any surface, whether it’s a paper label or a mobile phone display. This feature makes it ideal for applications like eCoupons, eTickets, Digital ID cards, and mobile payments, offering businesses the flexibility to adapt to evolving technology trends.



Rugged and Durable Design
MT8221 is built to withstand the rigors of harsh working environments. Its IP54-rated housing, featuring a rubber bezel that protects the scanner window, ensures durability and resistance to damage from drops up to 1.8 meters. This industrial-grade construction makes MT8221 a reliable choice for demanding applications where durability is a priority.

SPECIFICATIONS

Optic & Performance
Light Source
5600K white LED illumination
624nm red LED linear aimer
Sensor
640 x 480 pixels
Resolution
3mil (1D), 6mil (2D)
Scan Angle
Horizontal 41°
Vertical 31°
Pitch Angle
±60°
Skew Angle
±55°
Roll Angle
360°
Print Contrast Ratio
15%
Typical D.O.F (Environment: 800 lux)
5 Mil Code39: 32 ~ 174mm
13 Mil UPC/ EAN: 37 ~ 355mm
15 Mil QR Code: 19 ~ 203mm
10 Mil Data Matrix: 27 ~ 147mm
6.67 Mil PDF417: 33 ~145mm
Physical Characteristics
Dimension
L165.5 x W63.5 x H92.3 mm
Weight
160 g (w/o cable)
Color
Black
Material
Plastic
Connector
USB Type A
Cable
1.8M (Interchangeable Cable)
Trigger
Scan Button
Indicator
LED, Buzzer
Electrical
Operation Voltage
5 VDC ± 5%
Working Current
Typ. 200mA
Connectivity
Interface/Profile
USB HID
USB VCP
User Environment
Operating Temperature
-20 ~ 55˚C
Storage Temperature
-40 ~ 60˚C
Humidity
5%~95% RH (Non-condensing)
Drop Durability
1.8 M
Sealing
IP54
Surface Resistivity
Dark environment, indoor natural light (>105,500 lux)
Decode Capability
Symbologies
1D Symbologies:
UPC-A/ UPC-E, EAN-8/ EAN-13, Code128, GS1-128, Code 39, Code32, Code 93, Code11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5, Codabar, MSI, GS1 Databar, China Post, Telepen, Febraban, GS1 Composite, Japanese Post
2D Symbologies:
QR Code, Micro QR Code, Data Matrix, PDF417, MicroPDF417, Aztec, MaxiCode, HanXin
Regulatory
ESD
Functional after 4KV contact, 8KV air discharge
EMC/RF
EN55032/35
Safety Approval
EN62471
Environmental
WEEE, RoHS 2.0
